Commercial Air Filters
|
Automatic
Roll
Air Filters
|
Available in both fiberglass
and polyester media, Glasfloss Automatic Rolls are designed to replace
the original equipment filters without modification. A wide variety
of cores meet exacting standards to assure easy installation into existing
equipment.
-
Progressively
Dense Fiberglass or 100% Non-woven Polyester
-
Scrim Backing
-
Heavy-duty
Paper Leader and Trailer
-
Packaged
in Heavy-duty Plastic Bags and Cartons
APPLICATIONS...
Our
Automatic Roll Filters are designed to fit in automatic, semi-automatic
and manual type roll filter machines without modification to existing hardware.
Glasfloss Roll Filters shall incorporate progressively dense fiberglass
media or 100% non-woven polyester media. For added strength, the progressively
dense fiberglass and 100% non-woven polyester grades of media shall incorporate
a scrim backing on the air leaving side. Glasfloss Automatic Roll Filters
shall incorporate a heavy-duty paper leader and trailer that is sewn to
the media. The automatic roll filter's media standard length shall be sixty-five
feet. Each roll is packaged in a heavyduty plastic bag and carton that keeps
the media clean
until installation.
Fiberglass
Specifications
EC
II Automatic Roll Filters shall consist of a nominal 2" thick continuous
filament fiberglass of graduated density with a unidirectional scrim backing.
EC II media shall be blue in color. EC II media is engineered for moderate
dust loading applications.
The fiberglass shall be treated with a non-toxic, odor-free, non-migratory
tackifier. Heavy-duty kraft paper leader and trailer shall be sewn to
the media to facilitate installation and removal. The media shall be wound
on the specified core and shall be compatible for installation into the
original equipment without modification. The media shall be sixty-five
feet in length. The media shall have a 77% Average Arrestance per ASHRAE
52.1 Test Standard. EC II Automatic Roll Filters shall incorporate media
that is Class 2 under U.L. std. 900. The roll shall be packaged in a plastic
bag and heavy-duty carton to prevent contamination of the filter media.
Fiberglass
Specifications
1250
Automatic Roll Filters shall consist of a nominal 5/8" thick 100%
non-woven polyester media with a scrim backing. 1250 media is engineered
for moderate dust loading applications. 1250 media shall be white in color.
Heavy-duty kraft paper leader and trailer shall be sewn to the media to
facilitate installation and removal. The media shall be wound on the specified
core and shall be compatible for installation into the original equipment
without modification. The media shall be sixty-five feet in length. The
media shall have a 70% Average Arrestance per ASHRAE 52.1 Test Standard.
1250 Automatic Roll Filters shall incorporate media that is Class 2 under
U.L. std. 900. The roll shall be packaged in a plastic bag and heavy-duty
carton to prevent contamination of the filter media.
PHOENIX
Automatic Roll Filters shall consist of a nominal 3/4" thick 100%
non-woven polyester orange and white media with
a scrim backing. PHOENIX media is engineered for heavy dust loading applications.
PHOENIX media is impregnated during
manufacturing with a non-migratory tackifier. Heavy-duty kraft paper leader
and trailer shall be sewn to the media to facilitate
installation and removal. The media shall be wound on the specified core
and shall be compatible for installation into the original
equipment without modification. The media shall be sixty-five feet in
length. The media shall have an 88% Average Arrestance per ASHRAE 52.1
Test Standard. PHOENIX Automatic Roll Filters shall incorporate media
that is Class 2 under U.L. std. 900. The roll shall be packaged in a plastic
bag and heavy-duty carton to prevent contamination of the filter media.
ABOUT
FILTERS AND MERV RATINGSMERV RATINGS
(Minimum
Efficiency Reporting Value) are used by the HVAC (Heating, Ventilating
and Air Conditioning) industry to describe a filter's ability to remove
particulates from the air. A higher MERV rating means better filtration
and greater performance.
Click
here for additional info
